PoE Güç Kaynağı
PoE StandardıIEEE 802.3af, IEEE 802.3at
PoE Güç Pimi
Uzun mesafeli iletim bağlantı noktaları (17-24), 8 çekirdekli güç kaynağını destekler; Ethernet kablosu 1/2/3/6 ve 4/5/7/8 aynı anda güç kaynağı sağlar.
Yakın mesafeli iletim bağlantı noktaları (1-8) 4 çekirdekli güç kaynağını destekler, Ethernet kablosu 1/2/3/6 güç kaynağı sağlar.
PoE Bağlantı Noktası1-24 arası bağlantı noktaları
Maks. Alan Sayısı Liman Gücü30 W
PoE Power Pudget230 W
Maks. Alan Sayısı Güç Tüketimi250 W
Ağ Parametreleri
Port Numarası24 × 100 Mbps PoE bağlantı noktası, 1 × 1000 Mbps RJ45 bağlantı noktası ve 1 × 1000 Mbps SFP fiber optik bağlantı noktası
Bağlantı Noktası TürüRJ45 bağlantı noktası, tam çift yönlü, MDI / MDI-X uyarlamalı
StandartIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Yönlendirme ModuDepola ve iletme geçişi
Çalışma ModuStandart mod (varsayılan); Genişletme modu
Yüksek Öncelikli Bağlantı Noktaları1-8 arası bağlantı noktaları
Uzun Mesafe İletim Bağlantı Noktaları17 ila 24 numaralı bağlantı noktaları
MAC Adres Tablosu4 K
Anahtarlama Kapasitesi8,8 Gb / sn
Paket Yönlendirme Hızı6.547 Mp / sn
Dahili Önbellek2.75 Mbit
Genel
KabukMetal malzeme
Brüt Ağırlık3,33 kg (7,34 lb)
Net Ağırlığı2,55 kg (5,6 lb)
Boyut (L × H × D)335 mm × 44,5 mm × 226 mm (13,2 ”× 1,8” × 8,9 ”)
Çalışma Sıcaklığı-10 ° C - 55 ° C (14 ° F - 131 ° F)
Depolama Sıcaklığı-40 ° C ile 85 ° C (-40 ° F ile 185 ° F)
Çalışma Nemi% 5 -% 95 (yoğunlaşma yok)
Depolama Nemi% 5 -% 95 (yoğunlaşma yok)
Güç Kaynağı100-240 VAC, 50/60 Hz, Maks. 4 bir
Boştayken Güç Tüketim20 W
Onay
EMCFCC (47 CFR Bölüm 15, Alt Bölüm B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 + A1: 2015); RCM (AS / NZS CISPR 32: 2015); IC (ICES-003: Sayı 6, 2016)
EmniyetUL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013)
KimyaCE-RoHS (2011/65 / EU); WEEE (2012/19 / EU); Erişim (1907/2006 Sayılı Yönetmelik (EC))
