DONANIM ÖZELLİKLERİ | |
|---|---|
| Standartlar ve Protokoller | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Arabirim | • 6*10/100 Mbps RJ45 Ports with 4 PoE+ Ports (Port 1 to Port 4) • AUTO Negotiation/AUTO MDI/MDIX |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX: UTP category 5 or above cable (maximum 100m) |
| Fan Sayısı | Fanless |
| Harici Güç Kaynağı | External Power Adapter (Output: 53.5 VDC / 1.31 A) |
| Power Input | 220~240V, 50/60Hz (NV) |
| LED | Power, Link/Act, PoE Status |
| Paket Yönlendirme Hızı | 0.893 Mpps |
| PoE Portları (RJ45) | Standard: 802.3 af/at compliant PoE Ports: Port 1- Port 4 Power Supply: 65 W |
| Boyutlar ( W X D X H ) | 3.9×3.9×1.0 in (99.8×98×25 mm) |
| Maks. Güç Tüketimi | 66.53 W |
| Max. Heat Dissipation | 226.19 BTU/h |
PERFORMANS | |
|---|---|
| Anahtarlama Kapasitesi | 1.2 Gbps |
| Paket Buffer Belleği | 2048 Bytes |
| Advanced Features | • Extend Mode (Ports 1-4) • Isolation Mode (Ports 1-4) • PoE Auto Recovery (Ports 1-4) |
| Jumbo Frame | 2 KB |
YAZILIM ÖZELLİKLERİ | |
|---|---|
| MAC Adres Tablosu | 2K |
| İletim Metodu | Store-And-Forward |
DİĞERLERİ | |
|---|---|
| Paket İçeriği | Switch, Power Adapter, Rubber Feet, Installation Guide |
| Sertifikalar | CE, ROHS, KC, NTRA |
| Ortam | • Operating Temperature: 0°C to 40 °C (32 °F to 104°F ) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158°F ) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing |
