1 ~ 120 dakika (varsayılan: 60 dak), Ön kayıt: 1 ~ 30 sn, Post-kayıt: 10 ~ 300 sn
Video Algılama ve Alarm
Tetikleyen Olaylar
Kayıt, PTZ, Tur, Video Push, Snapshot ve Ekran İpuçları
Video Algılama
Hareket Algılama, MD Bölgeleri: 396 (22 × 18) ve Sabotaj
Alarm Girişi
–
Alarm Çıkışı
–
Playback ve Yedekleme
Senkronize Playback
1/4
Arama Modu
Zaman / Tarih, MD ve Tam Arama (Ikinci ile doğru)
Playback Fonksiyonu
Yürüt, Duraklat, Durdur, Geri Al, Hızlı oynat, Yavaş Oynat, Sonraki Dosya, Önceki Dosya, Sonraki Kamera, Önceki Kamera, Tam Ekran, Karışık, Yedek Seçimi, Dijital Zoom
Yedekleme Modu
USB Aygıtı / Network
Diğer Markalarla Uyumluluk
Diğer Markalarla Uyumluluk
Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec ve daha fazlası
Network
Arayüz
1 RJ-45 port (10/100Mbps)
PoE
4 ports (IEEE802.3at/af)
Network Fonksiyonu
HTTP / HTTPS, TCP / IP, IPv4 / IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filtresi, DDNS, IP Arama (Dahua IP kamera, DVR, NVS ve diğerlerini destekleme), Easy4ip
Fiber Optik Arayüz
–
Maks. Kullanıcı Erişimi
128 kullanıcı
Akıllı Telefon
iPhone, iPad, Android
ONVIF
ONVIF 2.4, SDK, CGI
Depolama
Dahili HDD
1 SATA III port, her HDD için 6 TB’a kadar kapasite
HDD Modu
Tek
eSATA
–
Arayüz
USB
2 ports (1 Arka USB2.0, 1 Ön USB2.0)
RS232
–
RS485
–
Güç
Güç Kaynağı
Tek, DC48V /1. 25A
Güç Tüketimi
NVR: <5.3W (HDD olmadan)
PoE: Tekli bağlantı noktası için maksimum 25.5W, toplamda 50w
Çevre Koşulları
Çalışma Koşulları
-10 ° C ~ + 55 ° C (+ 14 ° F ~ + 131 ° F), 86 ~ 106kpa
Dayanıklılık Koşulları
-20 ° C ~ + 70 ° C (-4 ° F ~ + 158 ° F), 0 ~ 90% RH
Kasa
Boyutlar
Kompakt 1U, 260mm x 224.9mm x 47.6mm
Net Ağırlık
0.8kg (HDD olmadan)
Sertifikalar
Sertifikalar
CE:EN55032, EN55024, EN50130-4, EN60950-1
FCC:Bölüm 15 Subpart B, ANSI C63.4-2014
UL:UL60950-1
