| İşlemsel |
| Baskı metodu | Direkt termal / Termal transfer Baskı |
| Baskı Çözünürlüğü | 203 DPI (8 dots/mm) |
| Baskı hızı (Maksimum) | 152 mm/saniye |
| Baskı uzunluğu | Max: 2540 mm |
| Baskı genişliği | Max: 108 mm |
| Hafıza | 32 MB DRAM (3.6 MB Kullanıcıya Ayrılmış) |
| 16 MB Flash ROM (8.4 MB Kullanıcıya Ayrılmış) |
| İşlemci | 32 bit RISC işlemci |
| İşlem arabirimleri | 1 adet düğme ve 2 adet LED |
| Haberleşme | Seri Port (RS-232C), USB (A/B) ve Ethernet |
| Etiket algılama sensörü | Yansıtmalı (Hareketli) ve birbirini görmeli (Ortada sabit) |
| Sertifikalar | CE, FCC, cULus, CCC, RoHS, BIS, BSMI, KC |
| Fiziksel |
| Genişlik | 226 mm |
| Yükseklik | 188 mm |
| Derinlik | 276 mm |
| Ağırlık | 2,1 kg |
| Kasa | ABS Plastik |
| Elektriksel |
| Güç giriş şekli | Harici elektrik adaptörü |
| Güç kaynağı (Giriş) | 100-240V, 50 ~ 60 Hz |
| Güç kaynağı (Çıkış) | 24V, 2.4A |
| Çevresel |
| Çalışma ortamı sıcaklığı | 4 °C ~ 38 °C |
| Saklama sıcaklığı | -20 °C ~ 50 °C |
| Saklama ortamı nem oranı | %0 ~ %90 (Yoğuşmasız) |
| Etiket |
| Tip | Ara boşluklu, Sürekli form, black mark (siyah çizgi ile ayrılmış) |
| Genişlik | 20 mm ~ 118 mm |
| Kalınlık | 0,06 mm ~ 0.2 mm |
| Kuka iç çapı | 25,4 mm |
| Etiket dış çapı | 127 mm (En fazla) |
| Ribon |
| Tip | Wax , Wax/Resin, Resin |
| Sarım yönü | İç Sarım veya Dış sarım |
| Uzunluk | 300 metre (En fazla) |
| Genişlik | 25,4 mm ~ 102 mm |
| Kuka iç çapı | 12,7 mm veya 25,4 mm |
| Ribon dış çapı | 67 mm |
| Yazılımsal |
| Windows sürücüleri | Win Vista / 7 / 8 / 8.1 / Win 10, Windows Server 2003 / 2008 / 2012 (32 Bit & 64 Bit) |
| Linux sürücüleri | Destekleniyor |
| Etiket dizayn programı | Bartender UltraLite (Ücretsiz) |
| Yardımcı programlar | Printer Utility ve Font Utility |
| Desteklenen barkod yazım dilleri | PPLA ve PPLB (Opsiyonel: PPLZ) |
| Desteklenen grafik biçimleri | PPLA: PCX, BMP, IMG, GDI ve HEX |
| PPLB: BMP, GDI ve Binary raster |
| PPLZ: GRF, HEX ve GDI |
| Desteklenen Barkod Tipleri |
| 1D | PPLA: CodeCode 39、UPC-A、UPC-E、Code 128 subset A/B/C、 EAN-13、 EAN-8、 HBIC、 Codabar、 Plessey、UPC2、 UPC5、 Code 93、 Postnet、 UCC/EAN-128, UCC/EAN-128 K-MART、UCC/EAN-128 Random weight、Telepen、FIM、I nterleaved 2 of 5 (Standard/with modulo 10 checksum/ with human readable check digit/ with modulo 10 checksum & shipping bearer bars) 、GS1 Data bar (RSS)
PPLB: Code 39, UPC-A, UPC-E, Matrix 2 of 5, UPC-Interleaved 2 of 5, Code 39 with check sum digit, Code 93, EAN-13, EAN-8 (Standard, 2 /5digit add-on), Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code) 、Code 128 auto、UCC/EAN code 128 (GS1-128) 、Interleave 2 of 5、Interleaved 2 of 5 with check sum、Interleaved 2 of 5 with human readable check digit、 German Postcode、 Matrix 2 of 5、 UPC Interleaved 2 of 5、 EAN-13 2/5 digit add-on、 UPCA 2/5 digit add-on、UPCE 2/5 digit add-on、 64 Compact Printer Series - User’s Manual GS1 Data bar (RSS)
PPLZ: Code39、UPC-A、UPC-E、Postnet、Code128 subset A/B/C、Interleave 2 of 5、Interleaved 2 of 5 with check sum 、Interleaved 2 of 5 with human readable check digit、Code 93、Code 39 with check sum digit、MSI、EAN-8、Codabar、Code 11、EAN-13、Plessey、 GS1 Data bar (RSS) 、 Industrial 2 of 5、Standard 2 of 5、Logmars |
| 2D | PPLA: MaxiCode、PDF417、Data Matrix (ECC 200 only) 、QR code、Composite Codes
PPLA: MaxiCode、PDF417、Data Matrix (ECC 200 only) 、QR code、Composite Codes
PPLA: QR code、、PDF417、Data Matrix (ECC 200 only) 、MaxiCode Composite Codes |
| Opsiyonel Seçenekler |
| Opsiyonel Seçenekler | Giyotin Kesici ünitesi (Tam Kesici)
Giyotin Kesici ünitesi (Parça Kesici)
Rotary Kesici ünitesi
Harici Etiket Kaynağı Ünitesi |
