| PBE-5AC-500 Sistemi ve Mevzuat/Uyumluluk |
| İşlemci Özellikleri | Ateros MIPS 74Kc, 720 MHz |
| Hafıza | 128 MB DDR2, 8 MB Flaş |
| Ağ Arayüzü | (1) 10/100/1000 Ethernet Bağlantı Noktası |
| Kablosuz Onaylar | FCC, IC, CE |
| RoHS Uyumluluğu | Evet |
| | |
| PBE-5AC-500 Fiziksel/Elektrik/Çevresel |
Boyutlar
Radom Hariç
Radom Dahil | 520 x 520 x 308 mm (20,47 x 20,47 x 12,13")
525 x 525 x 315 mm (20,67 x 20,67 x 12,40") |
Ağırlık
Radom Hariç
Radom Dahil | 2,35 kg (5,18 lb)
3,15 kg (6,95 lb) |
| Güç kaynağı | 24V, 0,5A Gigabit PoE |
| Güç Yöntemi | Pasif PoE (Çiftler 4, 5+; 7, 8 Dönüş) |
| Desteklenen Voltaj Aralığı | Desteklenen Voltaj Aralığı |
| Maks. Güç tüketimi | 8.5W |
| Kazanmak | 27 dBi |
Çalışma Frekansı
Dünya Çapında
ABD | 5150 - 5875 MHz
5725 - 5850 MHz |
| Rüzgar Yüklemesi | 419,6 N @ 200 km/sa (94,33 lbf @ 125 mph) |
| Rüzgara Dayanıklılık | 419,6 N @ 200 km/sa (94,33 lbf @ 125 mph) |
| Rüzgara Dayanıklılık | 200 km/sa (125 mil/sa) |
| LED'ler | (1) Güç, (1) LAN, (4) WLAN |
| Sinyal Gücü LED'leri | Özel RSSI Düzeylerine Karşılık Gelen Yazılımla Ayarlanabilir |
Kanal Boyutları
PtP Modu
PtMP Modu | 10/20/30/40/50/60/80 MHz
10/20/30/40 MHz |
| polarizasyon | Çift Doğrusal |
| muhafaza | Dış Mekan UV Stabilize Plastik |
| Montaj | Direğe Montaj Kiti Dahildir |
| ESD/EMP Koruması | Hava: ± 24 kV, Kontak: ± 24 kV |
| Çalışma sıcaklığı | 40 ila 70°C (-40 ila 158°F) |
| Çalışma Nemi | %5 ila %95 Yoğuşmasız |
