DONANIM ÖZELLİKLERİ | |
---|---|
Standartlar ve Protokoller | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3ab |
Arabirim | • 8*10/100 Mbps PoE+ RJ45 Ports + 2*10/100/1000Mbps RJ45 Ports • AUTO Negotiation/AUTO MDI/MDIX |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX: UTP category 5 or above cable (maximum 100m) • 1000BASE-T: UTP category 5e or above cable (maximum 100m) |
Fan Sayısı | Fanless |
Harici Güç Kaynağı | External Power Adapter (Power Input: 220~240V, 50/60Hz (NV), Output: 53.5 VDC / 1.92 A) |
LED | Power, Link/Act, PoE Status |
Paket Yönlendirme Hızı | 4.1664Mpps |
PoE Portları (RJ45) | Standard: 802.3 af/at compliant PoE Ports: Port 1- Port 8 Power Supply: 96 W |
Boyutlar ( W X D X H ) | 6.7×3.9×1.1 in (171×98×27 mm) |
Maks. Güç Tüketimi | 99.52 W |
Max. Heat Dissipation | 338.368 BTU/h |
PERFORMANS | |
---|---|
Anahtarlama Kapasitesi | 5.6 Gbps |
Paket Buffer Belleği | 2 Mbit |
Advanced Features | • Extend Mode (Ports 1-4/1-8) • Isolation Mode (Ports 1-8) • PoE Auto Recovery (Ports 1-8) |
Jumbo Frame | 2 KB |
YAZILIM ÖZELLİKLERİ | |
---|---|
MAC Adres Tablosu | 2K |
İletim Metodu | Store-And-Forward |
DİĞERLERİ | |
---|---|
Paket İçeriği | Switch, Power Adapter, Rubber Feet, Installation Guide |
Sertifikalar | CE, RoHS |
Ortam | • Operating Temperature 0°C to 40 °C (32 °F to 104°F ) • Storage Temperature -40 °C to 70 °C (-40 °F to 158°F ) • Operating Humidity 10% to 90% non-condensing • Storage Humidity 5% to 90% non-condensing |
