| Okuma Performansı |
| Image Sensor | 1 Megapiksel (1280 x 800 Piksel) |
| Işık Kaynağı | Odaklama: 2 Adet Mavi LED (470 nm) |
| Aydınlatma: 617 nm Kırmızı LED |
| Hareket Toleransı | 30 IPS |
| Yazdırma Karşıtlığı | %15 |
| Tarama Açısı | Pitch: ± 65°; Roll (Tilt): ± 360°; Skew (Yaw): ± 65° |
| Göstergeler (LED) | Ayarlanabilir Ses Tonu, Datalogic ‘Green Spot’ Işıkla Doğrulama, Doğrulama LED i |
| Çözünürlük | 1D: 0.077 mm(3 mil) |
| PDF417: 0.077 mm (3 mil) |
| Datamatrix: 0.127 mm (5 mil) |
| QrCode: 0.17 mm (6.7 mil) |
| Arabirimler | |
| Desteklenen Arabirimler | Klavye, RS-232C ve USB (Type-C) |
| Fiziksel | |
| Yükseklik | 148 mm |
| Derinlik | 126 mm |
| Genişlik | 68 mm |
| Ağırlık | 145 gr |
| Renk | Siyah |
| Elektriksel | |
| Giriş Voltajı | 5 VDC |
| Çalışma Akımı | <450 mA @5V |
| Beklemede | <90 mA @5V |
| Çevresel | |
| Işık Seviyesi | 100.000 Lux (Max.) |
| Çalışma Sıcaklığı | 0°C ~ 50°C |
| Muhafaza Sıcaklığı | -40 °C ~ 70 °C |
| Nem | %0 ~ %95 (Yoğuşmasız) |
| Düşme dayanıklılığı | 1,5 metre |
| IP Standardı | IP52 |
| ESD Koruması (Air Discharge) | 16 kV |
| Çözümleme Yeteneği | |
| 1D / Linear Kodlar | GS1/Databar Dahil Standart 1D Linear Kodlar |
| 2D Kodlar | Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Dot code |
| Postal Kodlar | Australian Post, British Post, China Post, IMB, Japanese Post, KIX Post, Planet Code, Postnet, Royal Mail Code (RM4SCC) |
| Stacked Kodlar | EAN/JAN Composites, GS1 DataBar Composites, GS1DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/E Composites |
| Digital Watermarking | Digimarc Barkodlar |
| Tarama Aralıkları | |
| 1D | Code 39: (5 mils) | 5 mm ~ 250 mm |
| Code 39: (10 mils) | 5 mm ~ 380 mm |
| EAN / UPCA: (13 mils) | 5 mm ~ 410 mm |
| 2D | PDF417 (6.7 mils) | 5 mm ~ 210 mm |
| Datamatrix: (10 mils) | 5 mm ~ 215 mm |
| QrCode: (20 mils) | 0 mm ~ 370 mm |
| Güvenlik ve Düzenleyiciler | |
| Kurum onayları (Sertifikalar) | Ürün kullanım için gerekli güvenlik ve mevzuata uygundur. Bu ürün için Hızlı Başvuru Kılavuzu, sertifikaların tam listesi için başvurulur. |
| Çevreye Uyum | Çin ve Avrupa RoHS uyumlu |
| LED Sınıflandırması | Aydınlatıcı Muaf grup, işaretçi Risk Grubu 1 IEC 62471'e göre |
| Araçlar | |
| Datalogic Aladdin | Barkod okuyucuyu yapılandırma yazılımı (Ücretsiz) |
| OPOS / JavaPOS | JavaPOS ve OPOS Yardımcı Programları indirilebilir (Ücretsiz) |
